3D Transparent Film Overwrapping Machine LS-200

The LS-200 is an automatic overwrapping machine designed for wrapping compatible rectangular and square cartons with transparent packaging film. It is suitable for manufacturers looking for a 3D film overwrapping solution that creates a neat outer package around individual boxes.

Depending on the product and packaging requirements, applications may include condom boxes, cosmetic boxes, perfume boxes, pharmaceutical cartons, contact lens boxes, soap boxes and other compatible rectangular products.

The machine is designed for automatic product overwrapping and can be evaluated for use with cellophane, BOPP (OPP), KOP and other compatible heat-sealable packaging materials. The final configuration depends on the product dimensions, film properties and required package appearance.

Contact LS-PACK to discuss your packaging requirements and confirm whether the LS-200 is suitable for your product.

Key Features of the 3D Overwrapping Machine

Transparent Film Overwrapping

The machine wraps compatible cartons with transparent packaging film to provide an outer protective layer and a finished package appearance. The final result depends on the selected film, carton dimensions and machine settings.

Overwrapping with Tear Tape

A tear tape can be included when supported by the confirmed machine configuration. Please specify whether tear tape is required when requesting a quotation.

Mechanical Drive System

The published product description identifies a cam-driven mechanical system. The machine configuration should be confirmed with LS-PACK based on the intended product and production requirements.

Adjustable Packaging Speed

The published packaging speed is 40–120 pieces per minute. Actual output depends on carton dimensions, material properties, feeding stability and operating conditions. Please confirm the expected production rate using your product samples.

Flexible Product Size Range

The published product size range is approximately 50–200 mm in length, 30–150 mm in width and 8–45 mm in height. Please provide your carton dimensions so the suitable machine configuration can be evaluated.

Applications of the Cellophane Overwrapping Machine

The LS-200 can be evaluated for transparent film overwrapping applications involving compatible cartons, including:

Condom boxes
Cosmetic and skincare boxes
Perfume boxes
Pharmaceutical cartons
Contact lens boxes
Soap boxes
Other suitable rectangular or square cartons

Application suitability depends on the product size, carton structure, packaging material and required finished-package appearance. Product samples should be tested before confirming the final setup.

Packaging Materials for Overwrapping

The published material options include cellophane, KOP, BOPP (OPP), heat-sealable film and paper. Not every material is suitable for every application or sealing configuration.

When requesting a quotation, please provide the film or paper specification, material thickness and any specific requirements for sealing, transparency or package appearance.

LS-200 Overwrapping Machine Specifications

Packaging speed	20-60 pcs/min
Packing dimensionmm)	(Length)50-200 (Width)30-150 (Height)8-45
Total power	3Kw
Power supply	220V 50/60Hz(customized)
Air consumption	0.4Mpa
Machine weight	490Kg
Machine dimensionmm)	16808701660
Conveyor dimensionmm)	10005401250
Packaging material	Cellophane, KOP, BOPP(OPP) and heat-sealable film or paper.

The published specifications include a packaging speed of 40–120 pieces per minute and a product size range of approximately 50–200 mm in length, 30–150 mm in width and 8–45 mm in height.

Please refer to the technical specification table on this page for the complete published configuration. Confirm all electrical, pneumatic and dimensional requirements with LS-PACK before ordering.

How to Choose a Cellophane Overwrapping Machine

Before selecting an automatic overwrapping machine, consider the following factors:

Product dimensions: Provide the length, width and height of your carton.
Packaging material: Specify cellophane, BOPP (OPP), KOP or another proposed material, together with its thickness and sealing properties.
Package appearance: Share photos or samples of the required 3D transparent film wrapping style.
Tear tape requirements: Confirm whether easy-opening tear tape is required.
Production output: State your target packaging speed and expected operating schedule.
Product feeding: Explain how cartons will be supplied to the machine and whether upstream or downstream equipment is needed.
